| Technical Specification: |
| Displacement (Cylinder Inhoud) |
13.47 |
ccm |
|
Output Power (Vermogen) |
|
kgf |
| |
kW |
| Carburetor |
Saito |
|
| Speed Range (Toerental) |
1700 - 9500 |
rpm (omw/min) |
| Propeller |
13x8 .. 14x8 |
inch |
| Ignition power supply (Spanning ontsteking) |
6 - 12V |
Volt |
| Spinner bolt diameter |
- |
mm |
| Spinner screw thread (Schroefdraad) |
M7 x 1 |
mm |
| Gas/Oil mix ratio (Brandstof verhouding) |
20 : 1 |
gas : oil |
| Weight: |
| Engine only (Engine mount: +124gr) |
528 |
gram |
| Muffler |
57 |
gram |
| Ignition |
110 |
gram |
| Documentation: |
| User Manual (Gebruikers Handleiding) |
FG-14C-Saito-Gas-Engines-Manual |
| Approx. Fuel Flow |
8cc/min
(at full throttle, 9000 rpm) |
| Link naar Fabrikant |
|
| Links: |
| SAITO Spare Parts |
|
The FG-14 4-stroke gas engine from Saito is especially developped for scale models.
Detailed overview of the delivery of the Saito FG-14 gas engine:
Dimensions of engine:
