TCG5625 TOMCAT G90 (330KV, 8 LiPo, 50A)
TOMCAT
TCG5625
Bestel
  • Beschrijving
  • Meer

The TOMCAT TCG5625 G90 is an engine suitable for models with a flying weight between 4.5 - 9 kg.

This engine is compatible with a gas engine of ~15cc.

 Model reference  TCG5625-KV330
 KV (RPM/V)  285
 No Load Current (A)  1.8
 No. of LiPo cells  6 - 8
 Max. Current 30s (A)  67
 Running Current (A)  <50
 Max. Input Power (W)  1800  (8 LiPo x 3,3V x 67A)
 Weight (g)  430
 Prop adapter diameter (mm)
 Shaft diameter (mm)  6
 Max. Pull (kg)
 Propellor (inch)  16x8 - 18x8
 Internal resistance (milli-ohm)    38
 Number of poles  14
 Maximum efficiency
 Dimensions  see below
 Manufacturer Website



Product delivery overview:





Motor dimensions of the TCG5625:
