Feature list:
- learning from the 250CC twin cylinder four-stroke motorcycle engine start
technology,optimized rotor coil technology, with super magnet and improved motor
efficiency without increasing power consumption, great power!
- 5.6:1 planetary gear box
- The use of high current deans connectors, reliable, durable
- Split power line design, convenient and flexible work.
- Stainless steel fasteners assembly
- CNC carved carbon fiber frame, high strength, light weight.
- Length of Power cable is ~1.5 m, ease of use!
- More powerful power Jig, small resistance!
Technical parameters:
-
12V, 9AH min. power supply
-
No-load speed 1000 rpm, with load more than 650rpm.
-
Maximum torque 120kg/cm
-
Can be used for 60cc - 250cc engines.
Below pictures deviate slightly from actual start engine. The connector is e.g. a Deans version which is not shown on the picture.
