New in stock.

UMS 5-Cylinder 180cc 4-stroke Radial Gas Engine Including ring muffler.

 Output Power

 10.9hp

 Propeller

 28x10 .. 28x12

 Weight

 4700g (incl.mufflers)

  Delivery includes: CM-6 spark plugs, ignition and ringmuffler.

Technical  Specification:
 Displacement                   (Cylinder Inhoud)  180  ccm

 Output Power                           (Vermogen)

 10.9  hp
   kW
 Carburetor

 Wt-621

 Walbro
 Static Thrust    kg
 Speed Range                             (Toerental)  1000 - 5500  rpm (omw/min)
 Propeller  28x10 .. 28x12  inch
 Ignition power supply (Spanning ontsteking)  6 - 9.6  Volt
 Spinner mount thread  M4  mm
 Crankshaft diameter  10  mm
 Gas/Oil mix ratio     (Brandstof verhouding)  30 : 1  gas : oil
 Weight:
 Engine                     (including muffler)  4700  gram
 Muffler  -  gram
 Ignition  610  gram
 Documentation:
 User Manual         (Gebruikers Handleiding)
 Approx. Fuel Flow  cc/min (full throttle)
 Link to manufacturer
 Links:
 Spare Parts



Spark plugs are of type: CM-6

5-Cylinder 180cc 4-Stroke Gas / Petrol Radial Engine

The UMS 5-180 is a new radial engine which uses gas fuel. UMS has a lot of experience building radial engines. It has brought more than 2000 engines to market so far. The design and construction are upper class leading to a outstanding realibility of these engines. They are easily servicebale. All critical parts are easily accessible.

Key Features

  • 5-cylinder radial configuration—absolutely stunning looks and realism
  • 4-stroke
  • Midsize 180cc displacement
  • Comes complete with exhaust collector ring —one-box purchase for a ready-to-mount-and-run engine
  • User-friendly choke and throttle bellcranks included—makes installation and operation easy
  • Made from aluminum or bar stock where appropriate and CNC-machined—accurate and repeatable specifications each and every time
  • Cylinder head and crankcases produced from aircraft grade alloys
  • Heavy-duty double bearing crankshaft
  • Billet aluminum pistons and hardened steel rings
  • Hard-chromed and lapped cylinder bores
  • Hardened steel cams
  • Burns gas/petrol fuel



The UMS-5-180cc 4-stroke radial gas engine from UMS is especially developped for scale models.

Engine dimensions:

Diameter: 275 mm, Length: 198mm
